Color: White
Dome shape
Image Sensor: 1/3" Sony Color CMOS Sensor
Horizontal Resolution: 1000 TV Lines
IR LEDs: 24
IR Distance: 50 - 60 feet
Lens: 3.6mm
Signal System: PAL/NTSC
Pixel Size: 3.75um x 3.75um
Dynamic Range: 95dB
IR Wavelengths: 50nm
Day & Night: Auto with IR LED board control
Minimum Illumination: 0.1 Lux/F1.2
S/N Ratio: ≥55dB
Electronic Shutter: PAL: 1/50-1/100,000s, NTSC: 1/60-1/100,000s
White Balance: Auto
Gain Control: Auto
BLC: Auto
HLC: Auto
Video Output: 1 vp-p, 75 Ohms, BNC connector
Synchronization: Internal
Gamma Correction: 0.45
Power Supply: DC 12V, 90mA - 100mA (IR LED off)
Built-in 15-inch cable with BNC video out and power input connectors
Dimensions:
3.5 x 3.8 x 3.8-inches (H x W x D, approximate)
Package Includes:
A-CMM02 1000 TV Line Infrared Night Vision Dome Camera
User Manual
Mounting Screws
1 year
